Efficiency at its best

You save time and money. The necessary connections are always available on site and ready to use. The thought-out product concept makes the pit system very easy to service and maintain and increases the service cycles. A closed system perfectly uses the available space underneath the apron as it can bear loads up to 40 tons.

pit system, pop up pit, pca, aircondition, hoses
pit system, pop up, pop up pit, pca, aircondition, hoses

Intelligent and simple design

The PCA pits simple design makes it reliable and durable. Due to the use of corrosion resistant materials, the pit system is perfectly prepared for the harsh environmental conditions on the apron. The intelligent construction at the hose outlet allows easy and fast extraction and retraction of the hose and the connector can be perfectly stowed.

Options

  • Explosion-proof and sand-protected versions available
  • Maintenance cover / shaft
  • Heater, water level detector and water pump

Advantages

  • Easy and ergonomic access to ground supply
  • Reliably and easily to open and close via an adjustable counterweight system
  • Immediately ready to use as soon as the equipment is raised
  • The concrete shaft can be produced in advance or on site
  • When unused, the system is lowered back safely into the ground – reducing the risk of accidents
  • Loading category EN124 F900 – up to 90 tons
